| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | UNO-PS/1AC/48DC/ 60W |
| Approvals | UL Listed ; cUL Listed ; cULus Listed ; UL Recognized ; UL Listed ; cUL Recognized ; cUL Listed ; IECEE CB Scheme ; cULus Recognized ; cULus Listed |
| Configuration | Enclosed |
| Input Voltage | 100 VAC ; 110 VAC ; 115 VAC ; 120 VAC ; 127 VAC ; 190 VAC ; 200 VAC ; 220 VAC ; 230 VAC ; 240 VAC |
| Mounting Type | DIN Rail Mount |
| Number of Outputs | 1 Output |
| Output Current | 1.25 A |
| Output Power | 60 W |
| Output Voltage | 48 VDC |
| Primary Type | AC-DC |
| Series | |
| Shop By | Factory Choice |
| Type | Industrial |
| UPC Code | 4046356808675 |
| Voltage, Input Range | 85-264 VAC |
Overview
Phoenix Contact UNO POWER Series – Compact, Basic Functionality Power Supplies:
The UNO POWER product range offers performance classes ranging from 25 to 240 W at output voltages of 5 to 48 V DC. UNO POWER allows input voltages from 85 to 264 V AC and functions reliably even in the event of voltage fluctuations in the power supply network. In the case of higher values from 264 to 575 V AC, the 2 AC device with 24 V and 90 W is used. Two devices with the designation C2LPS are certified according to UL 1310/508 Listed Class 2 and are ideal for the American market. Thanks to the wide range of products and the temperature range from -25°C to 70°C, the devices support flexible use.
Compared with other products on the market, using the UNO POWER power supply provides excellent energy savings, achieved through low idling losses below 0.3 W and optimized efficiency. With over 90% efficiency at nominal load, just a small amount of electrical energy is converted into undesired heat energy. UNO POWER supplies maximum power in the smallest space and is also available with 150 and 240 W output power. The output voltage can be set from 24 to 28 V DC via a potentiometer.
Features:
